Modem Router Wifi N300 ADSL 2+ Mercusys MW300D

MERCUSYS MW300D
300Mbps Wireless N ADSL2+ Modem Router

• Wi-Fi veloce – wireless 300 Mbps ideale per video streaming HD
• Ampia copertura – Due antenne esterne per una copertura Wi-Fi estesa in ogni direzione
• Massima compatibilità – Compatibile con ADSL2+/ADSL2/ADSL
• Configurazione semplice –interfaccia di configurazione web semplice ed immediata





Wireless

Wireless Standards

IEEE 802.11b/g/n

Frequency

2.4 – 2.4835GHz

Signal Rate

• 11n: Up to 300Mbps (Dynamic)
• 11g: Up to 54Mbps (Dynamic)
• 11b: Up to 11Mbps (Dynamic)

Reception Sensitivity

• 270M: -73dBm@10% PER • 11M: -90dBm@10% PER
• 130M: -75dBm@10% PER • 6 M: -94dBm@10% PER
• 54M: -77dBm@10% PER • 1 M: -96dBm@10% PER

Transmission Power

<20dBm (EIRP)

Wireless Security

WPA-PSK / WPA2-PSK

Wireless Functions

Enable/Disable Wireless Radio





Software

DHCP

Server



Hardware

Dimensioni (W X D X H)

114 x 94 x 26 mm

Button

WPS/Reset Button

External Power Supply

9V/0.6A

Tipologia di Antenna

2× External Antennas

Ethernet Ports

3*10/100Mbps LAN Ports
1*RJ11 Port



Other

Package Contents

• 300Mbps Wireless N ADSL2+
Modem Router (MW300D)
• Power Adapter
• Quick Installation Guide
• 2× RJ11 Phone Cable
• RJ45 Ethernet Cable
• External DSL Splitter

Environment

• Operating Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -40°C~70°C (-40°F~158°F)
• Operating Humidity: 10%~90% Non-Condensing
• Storage Humidity: 5%~90% Non-Condensing
